Perlick 15 Inch Outdoor Ice Maker with Solid Door

Description

Keep clear, top-hat-shaped ice ready for everyday drinks and relaxed entertaining. This Perlick standard-height ice maker fits a nominal 15-inch opening and is approved for indoor or outdoor use.

Key Features

• Produces clear, top-hat-shaped ice.
• Produces up to 51 pounds of ice per day, with storage for up to 22 pounds. Production varies with operating conditions.
• Stainless steel ice-making surface and an accessible power switch simplify routine care.
• Gravity drainage; Perlick drain pump 63802A is an optional accessory.

Specifications

• Model family: H50IMS / H50IMW; use the exact selected model reference below.
• Refrigerant: R134a, for this model generation.
• Electrical: 115 V, 60 Hz, single phase; 3.4 running amps.
• Operating ambient temperature: 45–100°F. Supply-water temperature: 45–90°F.
• Water pressure: 7–113 psig. Water supply and drainage are required.
• Item references: H50IMS-L; H50IMS-R; H50IMW.

Dimensions

• Overall: 14-7/8 inches wide × 22-9/16 inches deep × 33-1/2 inches high.
• Manufacturer specification-sheet opening: 15 inches wide × 24-7/8 inches deep × 34-1/2 inches high.
• Overall appliance measurements and installation-opening measurements are different. Confirm the final layout against the exact model drawing before building cabinetry.

Compatibility & Installation

• Do not assume a drain pump is included; use gravity drainage or the specified optional pump.
• Panel-ready variants require a customer-supplied overlay panel and handle; stainless steel variants have the factory door finish.
• The ice bin is not a freezer: ice melts and is replenished. Provide the required drain and regular cleaning.
• For fit or installation questions, contact Perlick at (800) 558-5592 with the appliance model and serial number.

WARNING: Perlick advises that materials in this product may contain chemicals known to California to cause cancer, birth defects or other reproductive harm. California Proposition 65 information.

Manufacturer Resources

• Perlick H50IMS / H50IMW generation-specific ice-maker specification
• Perlick manufacturer contact
