Harman Direct Vent Wall Pass Through Thimble with OAK- 3″ & 4″ Pellet Vent Pipe: 1-00-677177

Description

This direct vent wall pass-through thimble is made by Harman and is listed as a compatible venting component for Harman pellet stoves and inserts when using Simpson Pellet Vent Pro pellet venting.

Venting and 3″ OAK hose sold separately.

• The exhaust opening will accommodate both 3″ and 4″ vent diameters and a 3″ outside air flex hose.
• The term “direct-vent” means that this thimble supports exhaust venting AND an outside air connection all in one
• Supports the outside air temperature probe for stove models with a touchscreen controller
• Requires only one narrow opening for installation, 7 1/4″~7 1/2″ square
• Tough 316T stainless exterior with low profile intake hood
• Can accommodate a nominal wall thickness between 4″ and 10 5/8″

This wall pass-through thimble can be used for the Accentra 52i and P35i Inserts when the insert is bring installed into a an approved zero-clearance application.

P35i Zero-Clearance Box part, 1-00-774257

Accentra 52i Zero-Clearance Box part, 1-00-574205 (special Order)

Replacement For Part Number:

• 1-00-677177

UPC: 652174680764
