Harman Cast Pawl Retrofit Kit Door Handle Assembly: 1-00-453001

Description

The Cast Pawl Door Handle is the assembly commonly found on all Harman P Series Stoves made roughly around 2013 and after and was sold as a retrofit kit for older style pellet, coal, and wood-burning units. When installed as a retrofit, this assembly solved the common problem of the handle becoming loose because the pawl set screw would flatten or “strip” the threads of the pass-through bolt.

Standard Equipment on:

• P38 beginning 10328
• PC45 beginning serial 1530
• P43 (all units)
• P61A beginning serial 13547
• P68 (all units)

For Retrofit on (requires drilling a larger hole through the door)

• P38 pre serial 10327
• PC 45 pre serial 1529
• P61/P61A pre serial 13546
• 44 Mag (all units)
• TLC2000 (all units)
• DVC500 (all units)
• TL200 Exception (all units)

The retrofit kit is not compatible with Invincible Series

Replacement handle kit for older style, stoves, requires no modification to the existing door (which uses part 1-00-08704

.It is advised that whenever you are replacing a door latch, a new door gasket should also be installed to ensure the striker is set to the correct depth. Door gasket part for all models, 1-00-00888-20

Included in this kit:

• 1 x Cast handle (3-00-453001)
• 1 x Cast pawl (3-00-453002)
• 2 x 1/4-20 X 5/16” Screws (3-30-2925200312)
• 1 x 1/4-20 X 2-12” Screws (3-30-625202501)
• 2 x Wave washer (3-31-453013)
• 1 x Spacer for large doors (3-50-453003)
• 1 x Wooden handle (1-00-00247)
• 1 x 10mm drill bit (3-99-010)
• 1 x 1/8” hex key (3-99-712217)

With the exception of the wooden handle, individual replacement parts for this assembly are no longer sold individually by Harman

Replacement For Part Number:

• 1-00-453001

UPC: 652174546756
